Description
? Integrated single piece housing design – IP66 and IK06 protection
? 3 phase DOB design regulated at 170-264VAC / PF > 0.95 / DF > 0.9 / EMC passed / 2.5kV surge protection
? Refond SMD 2835, SDCM < 5 / RA > 84 / 100lm/w LM80 / TM21 / IES reports available
? Upgraded optical and housing design to the Neo
? Surface or suspension installation available
? Complies with standards of IEC60598-1&2 / CE /RoHS / EMC / SAA / ErP2.0
? 2 year warranty Academic, Civic, Public Spaces, Healthcare, Hospitality, Residential, Senior Living, Retail and Transportation
Additional information
| LEDs | Refond |
|---|---|
| Colour Temperature | 4000K, 5700K |
| Effective Lumen | 5800 lm |
| Colour Rendering Index | >84 |
| Power Factor | 0.95PF |
| Input Voltage | AC170 ~ 264V |
| Surge Protection | 2.5k V |
| Operating Temperature | -20°C – 50°C |
| Material | High Density Polycarbonate |
| Ingress Protection | High Pressure Water Resistant, IP66 |
| Impact Rating | IK06 |
| Dimension | 1452mm (L) 68mm (W) 38MM (H) |
| Lifespan | 35,000 Hours |
| Warranty | 2 Years |
| Certifications | CE, EMC, IEC, ROHS, SAA, ErP 2.0, LOA |
