ARCH Series LED Strip Light
The ARCH Series LED Strip Light 14.4W delivers high-efficiency, architectural-grade illumination with exceptional brightness and colour consistency. Designed for professional indoor installations, this DC24V strip offers high lumen output, dense LED spacing and superior light uniformity for commercial and residential applications.
Description
- High-performance 14.4W per metre LED strip light designed for architectural applications
- Operates on DC24V for improved efficiency and reduced voltage drop
- Produces up to 140 lm/W efficacy, delivering powerful and energy-efficient illumination
- High-density configuration with 160 LEDs per metre for smooth, consistent lighting
- LED spacing of 6.25mm ensures uniform light output with minimal shadowing
- Available in multiple colour temperatures: 2700K / 4000K
- High-quality white light suitable for professional installations
- Wide 120° beam angle for broad, even light distribution
- 50mm cutting intervals (8 LEDs per unit) for flexible customisation
- Maximum continuous length of 5 metres per reel
- PCB width of 10mm for compatibility with standard aluminium profiles
- Operating temperature range of -30°C to +60°C
- Storage temperature range of -20°C to +70°C
- IP20 rated for indoor, dry-area applications
- Ideal for commercial, retail, hospitality and residential projects
- Compatible with ARCH series connectors and accessories
- Certified for quality and reliability with LM-80 tested LEDs
- Backed by a 3-year warranty
Additional information
| Wattage | 14.4W |
|---|---|
| Effective Lumen | 1000lm ±5% |
| Colour Temperature (Kelvins) | 2700K, 4000K |
| Colour Rendering Index | >80 |
| Beam Angle | 120° |
| Power Factor | 0.9PF |
| Operating Temperature | -30°C to +60°C |
| Ingress Protection | IP20 |
| Input Voltage | DC24V |
| Cutout Size | 50mm |
| Warranty | 3 Years |
