18W Horizon CCT Anti Glare Downlighter – 5 Year Warranty
The Horizon range is the leader of the Mesmerize Anti-Glare integrated down-lighters. Backlit technology produces an even light-distribution without yellowing diffusors. Equipped with industry leading SMD2835 manufactured LED chips, this lighting solution offers the best performance for price in the market.
Description
- The Horizon has a specialized anti-glare design with a UGR<21 for 3 and 4-inch products, and an impressive UGR<19 for the 5, 6 and 8-inch variants.
- Switching 3-in-1 CCT for 3000K, 4000K and 5700K – reducing the need to hold all three colours in stock.
- The specially designed optics and reflector create a truly unique lighting experience.
- Selected SMD2835 LEDs with 100Lm/W laid in a Back-lit design with LGP, the light quality is unsurpassed with low risk of ‘yellowing’.
- The AL1060 aluminium housing improves the heat dissipation and improves lifespan.
- An External driver boasts a Power Factor of >0.9 and flicker free power output that gives the option for DALI 0 – 10V Triac dimming.
- The 1–2 kV surge protection assists in maintaining the rated lifespan of 50 000 hours and a 5-year Warranty.
- Reliably tested and approved by CE, CB, SAA, RoHs and ErP.
Additional information
| Wattage | 18W |
|---|---|
| LEDs | SMD 2835 |
| Colour Temperature | Built in 3 Colour by Dip-Switch – 3000K / 4000K / 5700K |
| Effective Lumen | 1500 lm |
| Unified Glare Rating | <21 |
| Colour Rendering Index | >84 |
| Dimmable | No |
| Beam Angle | 60° |
| Input Voltage | AC180~277VAC |
| Surge Protection | 1kV |
| Operating Temperature | -10°C ~ 40°C |
| Material | Aluminium |
| Ingress Protection | IP40 |
| Impact Rating | IK06 |
| Dimension | 145mm (D) * 73mm (H) |
| Cut Out Size | 120 – 130mm (D) |
| Lifespan | 50,000 Hours |
| Warranty | 5 Years |
| Certifications | CE, EMC, IEC, IES, ROHS, SANS |
